Description
Features:
● Flanges are designed according to ISO2861 specification and can be changed upon request.
● Flange size are from NW10 to NW50.
● Vacuum Range: ≥10-8Torr.
● Standard materials are 304 and 316L stainless steel.
● Tube sizes are from 1/2″ to 2″.
● The system can afford up to 400°F(200°C). Howerver, sustained baking above 302°F(150°C） may result in deterioration of the O-ring.
● KF products are supplied with a machining finish. Other finishes are also available.
● Flanges and seals are reusable.
● No tool for assembly or disassembly.
● KF flanges are each tested before shipping.
● Seal Tempreature Range:
Fluorocarbon FKM(Viton): -5°C~204°C(23°F~399°F)
Silicon: -50°C~180°C(-58°F~356°F)
Buna-N(NBR): -25°C~121°C(-13°F~250°F)
Applications:
● High Vacuum
● Roughing Line
● Vacuum systems, whitch require cleaning and modified frequently
● Experimental system in research laboratories
